CAT324

0 out of 5

Diverse modes: Two modes, Power and Smart, are available. The Power mode can deliver maximum output at all times, while the Smart mode can automatically match the engine and hydraulic power with the excavation conditions to save fuel.
– Convenient maintenance: Maintenance intervals are extended and more synchronized. The initial service life of the final drive and swing drive oil has been extended from 250 hours to 500 hours, and the replacement interval of the hydraulic oil filter is as long as 3000 working hours. Most daily maintenance points are accessible from the ground, and maintenance costs are 20% lower than those of the 323D2 series.
– Rich configurations: Product Link comes as standard, enabling remote monitoring of fuel consumption and other information via VisionLink. The cab is equipped with an 8-inch touchscreen monitor, automatic temperature control device, radio, USB port, etc., ensuring comfortable and convenient operation.

Free shipping on orders over $50!

Satisfaction Guaranteed
No Hassle Refunds
Secure Payments

GUARANTEED SAFE CHECKOUT

Description
Reviews (0)

Engine: Equipped with a Caterpillar C7 ACERT engine, with a rated power of 140 kW and a displacement of 7.2 liters. It adopts ACERT technology, featuring good fuel economy and low wear.
– Operating weight and bucket capacity: The overall operating weight is approximately 24,240 kg, and the bucket capacity is generally around 1 cubic meter.
– Hydraulic system: The maximum flow rate of the main pump is 235 liters per minute, the main relief setting pressure is 35 MPa, the pressure of the working hydraulic oil circuit and the travel hydraulic circuit is 35 MPa, and the pressure of the swing hydraulic circuit is 24.5 MPa.
– Working range: The maximum digging radius at the停机面 is 10,030 mm, the maximum digging depth is 6,740 mm, the maximum digging height is 9,660 mm, and the maximum dumping height is 6,700 mm.
