Doosan DL505

Basic Parameters

– Rated load capacity: 5000kg
– Overall operating weight: 16900kg
– Bucket capacity: 2.7m³
– Engine model: Weichai WD series engine
– Rated power: 162kW/2200rpm
– Maximum dumping height: 3210mm
– Dumping distance: 1170mm
– Fuel tank capacity: 300L
– Hydraulic oil tank capacity: 250L

Performance Features

– Powerful power: Optional Weichai WD series or WP10G220E343 electronic injection engine, with a rated power of 162kW and a maximum torque of 980N·m, providing strong power output to meet the operational needs of various harsh working conditions.
– Efficient operation: Adopting a dual-pump confluence hydraulic system, which increases the movement speed of the working device and improves work efficiency. The turning angle reaches 40°, and the minimum turning radius of the center line of the outer wheel is 5830mm, ensuring flexible operation and adaptability to narrow spaces.
– Comfortable and convenient: Equipped with a stamped cab, which has a large space, low noise and high safety, and is also equipped with an MP3 player, providing a comfortable operating environment. At the same time, each maintenance point of the equipment is easily accessible, making maintenance convenient.
– Good stability: Through rational design, the center of gravity is moved to the rear axle, which improves the stability of the equipment and makes it more reliable during operation.
