HYUNDAI 305

0 out of 5

Fuel tank capacity: 500L. A larger fuel tank capacity can reduce the frequency of refueling and improve operational continuity.
– Hydraulic oil tank capacity: 190L. The reasonable capacity of the hydraulic system helps ensure the stable operation of the hydraulic system.
– Comfortable cab: It provides a relatively comfortable operating environment for the driver, which helps reduce the driver’s work fatigue.

Free shipping on orders over $50!

Satisfaction Guaranteed
No Hassle Refunds
Secure Payments

GUARANTEED SAFE CHECKOUT

Basic parameters:
– Overall operating weight: 29700kg
– Bucket capacity: 1.38m³
– Engine model: Cummins QSB6.7
– Rated power: 169kW/1900rpm
– Swing speed: 10.2rpm
– Travel speed: 3.1-5.2km/h
– Climbing ability: 70/35°
– Ground pressure: 57Kpa
– Bucket digging force: 189.3kN
– Arm digging force: 136.3kN
– Performance characteristics:
– Powerful power: Equipped with a Cummins engine, the power output is stable and strong, which can meet the operation needs under various working conditions.
– Efficient hydraulic system: The main pump type is 2×variable axial piston pump + gear pump, the maximum flow of the main pump is 2×252L/min, and the working hydraulic oil circuit pressure is 34.3Mpa, which can provide stable and efficient hydraulic power to ensure that the excavator moves quickly and accurately.
– Large digging force: The bucket digging force is 189.3kN and the arm digging force is 136.3kN, which can easily handle various digging operations.
– Flexible operation: The swing speed and travel speed are moderate, with good maneuverability and flexibility, and can adapt to various complex working conditions.
– Wide operating range: The maximum digging radius is 10820mm, the maximum digging depth is 7500mm, and the maximum digging height is 10160mm, which can meet various operation needs.
