LG936

LG936L: The overall operating weight is 10,700kg, the fixed bucket capacity is 1.8m³, the rated load capacity is 3,000kg, it is equipped with a YC68125-T20 engine with a rated power of 92KW, the maximum unloading height is 2960mm, and the maximum speed is 38km/h.
– L936H: The total mass is approximately 10,750kg, the bucket capacity ranges from 1.5-3.0m³, the rated load capacity is 3,000kg, it is matched with a four-cylinder engine, has P, S, E three-level power control modes, adopts a self-made planetary power shift transmission, the steering angle is 37°, and the sum of three actions time is ≤9.0s.
– L936HEV: The rated load is 3,500kg, the operating weight is 11,500kg, it is standardly equipped with a 1.8m³ bucket, is equipped with 6 sets of CATL 180kWh lithium iron phosphate batteries, can work for 5-8 hours with dual-gun fast charging for 50 minutes, and the traveling motor is directly connected to the transmission, resulting in higher energy efficiency.

Performance Features

– Powerful power: For example, the engine of the L936H is powerful, with low noise and high reliability, and has a three-level power control mode, which can adjust the power output as needed to achieve fuel saving and high efficiency; the L936HEV adopts electric drive, with stable power output and significant energy-saving effect.
– Flexible operation: All are equipped with a load-sensing full hydraulic steering system, which is light and flexible to operate, with a large steering angle and small turning radius, facilitating operation in narrow spaces. Among them, the L936HEV also adopts a full hydraulic braking structure, making braking more reliable.
– Solid structure: Adopting heavy-duty box bridges and box-type frame design, the main blade of the L936H bucket uses a ladder-type wear-resistant steel structure, and the bottom wear-resistant plate is thickened. The battery of the L936HEV is equipped with a protective plate, which has waterproof, anti-corrosion, and dust-proof functions, ensuring the stability and durability of the equipment under harsh working conditions.
– Comfortable driving: The new-generation cab is designed according to ergonomics, with good sealing performance, equipped with a high-performance cooling and heating air conditioning system and a circulating air filtration system. The L936H and L936HEV also adopt high-grade suspended seats, with a large operating space, providing a comfortable driving experience.
