XCMG 50T

The maximum rated lifting weight is 50 tons, the total length of the whole machine is 13100mm, the total width is 2750mm, the total height is 3360mm, the wheelbases are 1520mm, 3815mm, and 1350mm respectively, the outrigger span is 5.65m in the longitudinal direction and 6.6m in the transverse direction, the maximum lifting height of the main boom is 40m, the maximum lifting height of the jib is 55.8m, the maximum lifting torque of the basic boom is 1764kN·m, and the maximum lifting torque of the longest main boom is 823.2kN·m.Strong lifting capacity: Equipped with a five-section elliptical telescopic main boom and a two-section folding jib, it has a large operating range and can meet various hoisting needs.
– Precise and comfortable operation: Adopting hydraulic pilot control technology, two handles can control all actions of the upper vehicle. The electric proportional control system makes the operation more precise and effortless. The full-head cab and new operating room provide a wide field of vision and comfortable operation.
– High safety performance: Equipped with safety devices such as a fully automatic load limiter, height limiter, and wire rope over-release device, which can effectively ensure operational safety.
– Powerful power: Adopting a high-power and environment-friendly engine, it has strong power and good passability, and can adapt to different working environments.
– Convenient maintenance: The control components adopt an integrated and modular design, resulting in low system energy loss and high efficiency. High-precision hard pipes and ferrule-type joints improve the cleanliness of the hydraulic system, avoid leakage, ensure high reliability of the system, and facilitate maintenance.
