XCMG QY130K

Technical Parameters: Maximum rated lifting capacity is 130 tons, and the maximum lifting torque of the basic boom is 5003 kN·m. The main boom is a six-section telescopic boom with a maximum length of 58 meters. It is standardly equipped with 3 jibs, which are 11.5 meters, 20 meters, and 28 meters long respectively. The maximum length of the main boom plus jib can reach 86 meters. The longitudinal distance of the outriggers is 7.56 meters, and the transverse distance is 7.6 meters. The total length of the whole machine is 14950 mm, the total width is 3000 mm, the total height is 3950 mm, and the maximum driving speed is 70 km/h.
– Power System: Adopts a dual-engine configuration for the upper and lower vehicles. The rated power of the lower vehicle engine is 294 kW, and the rated power of the upper vehicle engine is 120 kW, providing strong power.
– Boom Design: Six-section “U-shaped” boom, made of imported high-strength WELDOX960 steel plate, with strong anti-twisting ability. The single-cylinder pin-type fully automatic quick telescopic system can realize various boom length combinations, with 36 boom length telescopic combination modes.
– Safety and Comfort: Equipped with safety devices such as a torque limiter and an anti-overturning system to ensure operational safety. The rotatable operating room has a wide field of vision, is designed using ergonomic principles, and has high operating comfort.
