LW500FV

Basic Parameters

– Rated load capacity: 5000kg.
– Total machine weight: 17000±300kg.
– Rated power: 170kW (some data shows 162kW).
– Bucket capacity: The standard bucket capacity is 2.8m³, and buckets of 3.0~4.5m³ can be selected according to different materials.

Performance Features

– Power system: Adopts Weichai (optional Shangchai) electronically controlled high-pressure common rail energy-saving engine. Fuel injection is controlled by ECU, with high combustion efficiency. It can also choose three power modes: light load, medium load and heavy load to maximize fuel saving.
– Hydraulic system: Equipped with a large-displacement dual-pump confluence hydraulic system, the oil cylinder has strong force, fast arm lifting, faster loading speed and high operating efficiency.
– Structural design: Structural parts adopt finite element analysis technology to reduce stress concentration, eliminate local weak points, and make them more solid and reliable. At the same time, it adopts a golden wheelbase platform design, with a small turning radius and good site adaptability.

Cab and Operation

– Comfort: It has a luxurious cab equivalent to the level of a car, with large space, exquisite interior, and operating elements and buttons within easy reach, making operation convenient.
– Safety: The full-view rear glass is matched with high-mounted rear lights, providing good visibility and safe reversing.

Maintenance

The hood adopts an upward-turning large side door structure with a large opening angle, allowing easy access for regular maintenance. The gearbox, drive axle, etc. adopt a dust-proof labyrinth type breather structure, which effectively prevents external dust from polluting various systems and reduces maintenance costs.
