XCMG RP185

Engine: The Cummins 6CTA8.3-C190-II engine is commonly used, with a rated power of 142kW and a rotational speed of 2200rpm.
– Overall dimensions: The overall appearance (standard configuration) is approximately 8900x2625x3420mm.
– Overall weight: Approximately 15400kg in standard configuration.
– Tire specification: 17.5-25.

Performance Features

– Working device: The blade is 3965mm long with a chord height of 610mm, a maximum lifting height of 460mm, a maximum digging depth of 500mm, a maximum tilting angle of 90°, a cutting angle of 28°-70°, and a rotation angle of 360°, which can meet various operational needs.
– Transmission system: Equipped with Liuzhou ZF gearbox, 6 forward gears and 3 reverse gears, with flexible and convenient power shift operation. The rear axle is a three-section drive axle with an imported self-locking differential, ensuring smooth and reliable transmission.
– Brake system: The service brake system uses imported hydraulic components, with hydraulic drum brakes acting on the four middle and rear drive wheels; the parking brake system uses drum brakes acting on the output shaft of the gearbox to ensure driving safety.
– Steering system: Adopts a load-sensing, steering-priority energy-saving full hydraulic system, combined with an articulated frame, making steering flexible and maneuverable, with a minimum turning radius of 7.3m.
– Cab: Uses a unique diamond-shaped forward-tilting cab with a wide field of vision, good sealing, and low noise. It is equipped with advanced facilities such as an ABS adjustable console, adjustable seats, imported instruments, audio, and roof-mounted air conditioning, ensuring comfortable driving.
